Feature
• Hot-pluggable QSFP-DD form factor
• 8 channels full-duplex transceiver module
• 8x 850nm VCSEL array and PIN photo-detector array
• Internal CDR circuits on both receiver and transmitter channels
• Compliant with QSFP-DD MSA, IEEE 802.3cd 200GBASE-SR4
and CMIS
• Data rate up to 425Gbps (8x PAM4 53Gbps)
• Reach up to 70m (OM3) or 100m (OM4) over MMF with FEC
• Power consumption < 10W
• MPO24 receptacle
• Built-in digital diagnostic functions
• Operating case temperature range from 0°C to 70°C
• 3.3V power supply voltage
• RoHS compliant (lead free)
Application
• 2x 200GBASE-SR4 Ethernet
| Part No. | Form Factor | Data Rate(Gb/s) | Reach | Wavelength | Transmitter（dBm） | Receiver(dBm) | Inlerface | Temperature |
|---|---|---|---|---|---|---|---|---|
| OLSQ85FXM-CDS1 | QSFP-DD SR8 | 425G | PAM4 100m | 8x850nm VCSEL | -6.5~4 | <-6.5 | MPO24 | 0~70 |
