Product Features
• Duplex LC receptacle optical interface
• Single +3.3V power supply
• Hot-pluggable QSFP28 MSA form factor
• 4x25G Electrical Serial Interface
• Compliant with 4x28G(CEI-28G-VSR)
• AC coupling of CML signals
• Transmitter: cooled 4x25Gb/s LAN WDM EML TOSA (1295.56, 1300.05, 1304.58, 1309.14nm)
• Receiver: 4x25Gb/s PIN ROSA
• Low power dissipation(Max:6W)
• Built in digital diagnostic function
• Operating case temperature range:0℃ to 70℃
• Compliant with 100GBASE-LR4
• I2C Communication Interface
Applications
• 100GBASE-LR4
• Infiniband QDR and DDR interconnects
• 100G Datacom connections
